Pvc Coated Gabion Box
pvc coated gabion box for sale,welcome to contact us now.
Anping County wire mesh products bozhong Ltd, registered capital of 58.88 million Yuan. In just a few years has developed a wire drawing equipment 50; galvanizing line 15; gabion machine 20; machines for straightening, spring 25, packaged compression equipment 15 gabion production scale. Year 6.5mm more than 30000 tons of wire rods, daily production of gabion production capacity of more than 50000 square meters. Products are major rivers and hillside areas, are exported to United States, and Germany, Japan, and Canada, Southeast Asia, Middle East, Africa and other countries.
The gabion is made of high corrosion resistance, high strength, ductile low carbon steel wire or PVC coated steel. The box structure is made of gabion cage. According to ASTM and EN standards, the diameter of the low carbon steel wire used varies depending on the engineering design requirements. Generally between 2.0-4.0mm, gabion steel wire tensile strength of not less than 38kg / m2, metal coating weight is generally higher than 245g / m2, stone cage mesh edge diameter is generally greater than the diameter of the cable. The length of the double-stranded part shall not be less than 50mm in length to ensure that the metal coating and the PVC coating of the stranded wire are not damaged.
Pvc Coated Gabion Box
parameter
(1) Aperture: 60 * 80mm, 80 * 100mm, 80 * 120mm, 100 * 120mm, 120 * 150mm, 90 * 110mm
Wherein the length of the twisted portion is not less than 50 mm in order to ensure that the metal coating and the PVC coating of the stranded portion are not damaged.
(2) wire diameter: gabion net three kinds of wire diameter - wire, edge silk, tied wire
1. Mesh ranges from 2mm to 4mm
2. Edge silk is generally greater than the mesh, 0.5-1.0mm thicker than the mesh
3. Binds the wire is generally less than the mesh, the common to 2.2mm majority
(3) wire tension: not less than 38kg / m2 380N / mm
(4) surface treatment
1. galvanized. The maximum zinc content is 10g / m2. Poor corrosion resistance
Hot dip galvanized. The maximum amount of zinc can reach 300g / m2. Strong corrosion resistance
3. Golfer (Zinc Aluminum). This is divided into two kinds of materials, zinc-5% aluminum-mixed rare earth alloy steel wire, zinc-10% aluminum mixed rare earth alloy steel wire. Anti-corrosion super
4.PVC plastic package. The thickness of the plastic package is generally 1.0mm thick, for example: 2.7mm package after 3.7mm. Strong anti-corrosion
(1) cut off: in the long direction of the gabion every one plus a partition
(2) Size: can be customized according to the standard
(3) the diameter of the diameter of the control of the scope
